Micro SA ionONE Spot Ionizer with Air Assist and Self Balancing Technology

The Simco-Ion 91-MICRO SA-02 is a Micro S spot ionizer with air assist designed to control static electricity in the confined spaces of production tools or assembly applications.

• Efficiently controls static electricity by neutralizing charges to a small target area
• Use compressed dry air to provide static control where no existing airflow is available
• Compact design allows installation in the confines of any process tool or application
• Self-balancing technology ensures the correct combination of positive and negative ions
• Easy maintenance of the emitter points is required
• Indicates the power applied to the ionizer
• Efficiently controls static electricity by neutralizing charges to a small target area

• Input voltage: Isolated 12 VDC, 30 mA
• Balance: <±20V
• Discharge: <10 seconds at 6" (150mm), 20 lpm airflow min
• Coverage area: 6 x 6" (150x150mm) at 6"
• Air supply: Clean dry air (CDA)
• Ambient airflow: 200 ft/min (1.0m/sec) minimum recommended
• Air fitting: 4 mm OD, barbed
• Emitter points: Stainless steel
• Air consumption: Micro SA: 10-30 liters/min
• Audible noise: 67 dB @ 1" distance using 20 lpm air
• Enclosure: Polycarbonate-ABS plastic blend
• Cleanliness: Meets ISO 14644-1 Class 5 (Fed. Std. 209E Class 100)
• Operating environment: 40-122°F (5-50°C) 30-70% RH, non condensing
• Certifications: RoHS 2 compliant
• Dimensions:
  • Length: 2"
  • Width: 1-5/8"
  • Height: 11/16"
• Weight: 0.67 oz (19g)
